Hyundai has revealed the full breakdown of variants, technical specifications, and colour choices for the Hyundai BAYON. Designed to cater to a wide range of driving preferences and lifestyle needs, the new Intelligent Utility Vehicle comes with an impressive trim options, choice of manual and automatic powertrains, and a rich mix of exterior finishes.
Key Technical Specifications & Dimensions
The Hyundai BAYON is powered by a trusted 1.5-litre four-cylinder MPi petrol engine, offering a balanced combination of power, efficiency, and driving refinement.
| Specification / Dimension | Details |
| Engine Configuration | 4 Cylinders |
| Displacement | 1,497 cc (1.5L MPi Petrol) |
| Max Power Output | 84.4 kW (115 PS) @ 6,300 rpm |
| Max Torque Output | 143.8 Nm (14.7 kgm) @ 4,500 rpm |
| Transmission Options | 6-speed Manual Transmission (6MT) / Intelligent Variable Transmission (iVT) |
| Overall Length | 4,245 mm |
| Overall Width | 1,810 mm |
| Overall Height | 1,605 mm (with roof rails) |
| Wheelbase | 2,600 mm |
| Fuel Tank Capacity | 43 Litres |
| Front Suspension | McPherson strut with coil spring |
| Rear Suspension | Coupled torsion beam axle with coil spring |
| Brakes Setup | Front Discs; Rear Drums / Discs (varies on trim level) |
| Tyre Options | 205/65 R16 Steel wheel with wheel cover (D=405.6 mm) 215/55 R17 Styled steel wheel (D=436.6 mm) 215/55 R17 Diamond cut alloy wheel (D=436.6 mm) |
| Spare Wheel / Mobility | 195/65 R15 Steel wheel (D=380.2 mm) for most variants; Tyre Mobility Kit (TMK) provided for the 1.5 petrol HX2 variant |
Trim Levels & Transmission Breakdown
Hyundai is offering the BAYON across multiple well-defined variants. Buyers can select between the traditional 6-speed Manual Transmission or the convenient Intelligent Variable Transmission (iVT) depending on the trim:
- Manual Transmission (6MT) Variants: HX2, HX3, HX3+, HX5, HX6, HX8, and HX10.
- Intelligent Variable Transmission (iVT) Variants: HX5 iVT, HX6 iVT, HX8 iVT, and HX10 iVT.
Palette of 10 Exterior Colour Options
To ensure buyers stand out on the road, the Hyundai BAYON comes in 10 distinct exterior shades categorized into Monotone, Dual-Tone, and Matte finishes:
- Monotone Colours: Titanium Black, Classy Blue, Atlas White, Fiery Red, Golden Bronze, and Ecotronic Grey.
- Dual-Tone Colours: Atlas White with Black Roof, and Fiery Red with Black Roof.
- Matte Colours: Titanium Black Matte, and Classy Blue Matte.
My Thoughts
“Hyundai structuring the BAYON line up with seven manual options and four iVT automatic trims gives Indian buyers complete flexibility depending on their budget and feature requirements. While even the base versions are decently loaded, offering options like diamond-cut 17-inch alloys, rear disc brakes on top trims, and factory matte paint choices straight out of the showroom is a clear win for the customers. The best however has to be the multiple trims within the iVT choice.”
— Avin Richards
